Pusher Blade (Fluid Edge)
Pile it fast and high with the AMI Reactor Pusher Blade. Simply connect the Pusher to your loader using a quick coupler and get ready to gather and push using the boxed endplates for maximum volume. With a spring-trip on the cutting edge, the AMI Reactor Pusher Blade is strong, tough and forgiving. Gain the upper edge and improve your snowplowing capabilities this winter with the all-new FluidEdge Segmented Cutting Edge. Featuring individual 12” segments that respond and conform to uneven surfaces, FluidEdge provides exceptional snow clearing no matter what conditions winter throws at you. With minimal moving parts - only an Hardox 500 cutting edge and a rubber suspension block - FluidEdge boasts a simple design that is also easy to service and maintain. Requiring only two bolts and two nuts, replacing an FluidEdge segment is an easy one-person job. Because you don’t need to replace the entire blade, FluidEdge is also an economical solution to lowering costs for your snowplowing fleet.
12-INCH SEGMENTS
RUBBER SUSPENSION BLOCK
Hardox 500
FLEXIBLE CUTTING EDGE
5 DEGREE TILT
1.5" Vertical Travel
Specifications - Loader Backhoe
| FastTrack | Category | Model | Machine Class | Width | Height | Weight |
|---|---|---|---|---|---|---|
| 30 | SB307PFE2LB | Class 30 | 7 ' | 38 " | 1107 lbs | |
| 30 | SB308PFELB | Class 30 | 8 ' | 38 " | 1192 lbs | |
| 30 | SB309PFE2LB | Class 30 | 9 ' | 38 " | 1100 lbs | |
| 30 | SB310PFELB | Class 30 | 10 ' | 38 " | 1362 lbs | |
| 30 | SB312PFE2LB | Class 30 | 12 ' | 38 " | 1560 lbs | |
| 50 | SB410PFELB | Class 50 | 10 ' | 34 " | 2075 lbs | |
| 50 | SB412PFE2LB | Class 50 | 12 ' | 34 " | 2265 lbs | |
| 50 | SB414PFE2LB | Class 50 | 14 ' | 34 " | 2460 lbs | |
| 70 | SB410PFELB | Class 70 | 10 ' | 34 " | 2075 lbs | |
| 70 | SB412PFE2LB | Class 70 | 12 ' | 34 " | 2265 lbs | |
| 70 | SB414PFE2LB | Class 70 | 14 ' | 34 " | 2460 lbs |
AMI’s Fast Track Program features a wide selection of high-volume products that can be manufactured and shipped in a shorter time period with no compromise in quality and at no extra charge.
