Graptor® Bucket

When you need to pick up large, heavy objects, grab bucketfuls of debris or demolish a building, get a tighter grip on productivity with AMI’s Graptor® Bucket. Powered by a helical actuator, the Graptor® Bucket features incredible holding strength. The built-in rotary actuated thumb gives operators improved flexibility and precision by maintaining constant grip on the load throughout the bucket’s entire rotation. Neatly integrated into the top crossbar of the Graptor®, the actuator produces up to 54,000 foot-pounds of holding strength at 3,000 psi – putting out the most torque in the most compact design - making the Graptor® a powerful tool that keeps a tight handle on heavy, bulky loads. US patents 10,774,498 and 10,774,501.


Helical Actuator


Constant Grip


Heavy Duty Construction


Enclosed Hydraulics

Specifications - Compact Excavator

FastTrack Category Model Machine Class Width Capacity Teeth Grapple Tines Weight
50 GRHDRC1012E24 10,000 - 12,000 lbs 24 " 4.675 ft³ 4 3 616 lbs
60 GRHDRC1214E24 12,000 - 14,000 lbs 24 " 8.109 ft³ 4 3 929 lbs
60 GRHDRC1214E30 12,000 - 14,000 lbs 30 " 10.470 ft³ 4 3 951 lbs
75 GRHDRC1416E24 14,000 - 24,000 lbs 24 " 8 ft³ 4 3 929 lbs
75 GRHDRC1416E30 14,000 - 24,000 lbs 30 " 10.470 ft³ 4 3 951 lbs

FastTrack Logo AMI’s Fast Track Program features a wide selection of high-volume products that can be manufactured and shipped in a shorter time period with no compromise in quality and at no extra charge.
