HD Pro Digging Bucket – Symmetrical
Next Generation Productivity that Cycles Faster and Maximizes Payload. Welcome to a whole new level of digging bucket that delivers greater payload performance without sacrificing wear life or impact resistance. AMI PRO Series Symmetrical buckets are strong, last just as long and weigh less - gaining extra payload capacity without upsizing your excavator. The AMI PRO Series Symmetrical buckets are designed for use with symmetrical couplers and fit with AMI thumbs, AXXIS TR and RC couplers as well. Step into the next generation of productivity with an advantage that adds up on every pass. Contact your local AMI Attachments dealer or call 1-800-556-9452.
Hardox® In My Body
Lighter-weight Hardox® 500 Tuf steel delivers proven durability, allowing more material to be moved without increasing suspended load.
Material Type
Smooth Outer Shell
By eliminating the need for heavy wear bars, PRO Series buckets are lighter weight and reduce drag for efficient breakout of material.
Full Pull
With a forward edge position, PRO Series buckets penetrate material naturally with less bucket curl required. PRO offers better visibility to the operator and fills faster by pulling through material easier.
Improved Fill Factor
PRO’s profile is capable of holding over 100% fill factor, depending on material.
Lugging Made with Strenx®
Stress and strain across the lugging is handled through high tensile Strenx® performance steel that flexes without cracking.
Speed Load Dual Radius
The dual radius shell in combination with the forward edge position allows the bucket to fill quicker, increasing dig cycle times and reducing partial bucket loads. When curling the bucket the dual radius improves heel clearance saving unnecessary exterior wear.
Low Resistance Tapered Sidewalls
The tapered design improves side wall clearance for less digging resistance and reduced side wear, reducing friction at discharge.
Bucket Selection Guide By Material Application
Specifications - Excavator
| FastTrack | Category | Model | Machine Class | Weight | Width | Capacity | Teeth |
|---|---|---|---|---|---|---|---|
|
130 | HDPFT2433E24 | 24,000 - 33,000 lbs | 665 lbs | 24 " | 0.48 yd³ | 4 |
| 130 | HDPFT2433E30 | 24,000 - 33,000 lbs | 750 lbs | 30 " | 0.63 yd³ | 4 | |
|
|
130 | HDPFT2433E36 | 24,000 - 33,000 lbs | 850 lbs | 36 " | 0.79 yd³ | 5 |
| 130 | HDPFT2433E42 | 24,000 - 33,000 lbs | 935 lbs | 42 " | 0.94 yd³ | 5 | |
| 130 | HDPFT2433E48 | 24,000 - 33,000 lbs | 1035 lbs | 48 " | 1.10 yd³ | 6 | |
| 150 | HDPFT3340E24 | 33,000 - 45,000 lbs | 710 lbs | 24 " | 0.54 yd³ | 4 | |
|
|
150 | HDPFT3340E30 | 33,000 - 45,000 lbs | 795 lbs | 30 " | 0.72 yd³ | 4 |
|
|
150 | HDPFT3340E36 | 33,000 - 45,000 lbs | 900 lbs | 36 " | 0.91 yd³ | 5 |
|
|
150 | HDPFT3340E42 | 33,000 - 45,000 lbs | 985 lbs | 42 " | 1.10 yd³ | 5 |
| 150 | HDPFT3340E48 | 33,000 - 45,000 lbs | 1090 lbs | 48 " | 1.29 yd³ | 6 | |
| 200 | HDPFT4045E30 | 45,000 - 55,000 lbs | 1230 lbs | 30 " | 0.84 yd³ | 4 | |
|
|
200 | HDPFT4045E36 | 45,000 - 55,000 lbs | 1390 lbs | 36 " | 1.06 yd³ | 5 |
|
|
200 | HDPFT4045E42 | 45,000 - 55,000 lbs | 1510 lbs | 42 " | 1.28 yd³ | 5 |
|
|
200 | HDPFT4045E48 | 45,000 - 55,000 lbs | 1670 lbs | 48 " | 1.51 yd³ | 6 |
| 200 | HDPFT4045E54 | 45,000 - 55,000 lbs | 1790 lbs | 54 " | 1.74 yd³ | 6 | |
| 250 | HDPFT4560E30 | 55,000 - 65,000 lbs | 1400 lbs | 30 " | 0.95 yd³ | 4 | |
| 250 | HDPFT4560E36 | 55,000 - 65,000 lbs | 1565 lbs | 36 " | 1.20 yd³ | 5 | |
|
|
250 | HDPFT4560E42 | 55,000 - 65,000 lbs | 1705 lbs | 42 " | 1.47 yd³ | 5 |
|
|
250 | HDPFT4560E48 | 55,000 - 65,000 lbs | 1870 lbs | 48 " | 1.73 yd³ | 6 |
| 250 | HDPFT4560E54 | 55,000 - 65,000 lbs | 2005 lbs | 54 " | 2.00 yd³ | 6 | |
| 250 | HDPFT4560E60 | 55,000 - 65,000 lbs | 2170 lbs | 60 " | 2.27 yd³ | 7 | |
| 300 | HDPFT6080E36 | 65,000 - 90,000 lbs | 2460 lbs | 36 " | 1.50 yd³ | 4 | |
| 300 | HDPFT6080E42 | 65,000 - 90,000 lbs | 2660 lbs | 42 " | 1.82 yd³ | 4 | |
|
|
300 | HDPFT6080E48 | 65,000 - 90,000 lbs | 2930 lbs | 48 " | 2.16 yd³ | 5 |
|
|
300 | HDPFT6080E54 | 65,000 - 90,000 lbs | 3140 lbs | 54 " | 2.50 yd³ | 5 |
| 300 | HDPFT6080E60 | 65,000 - 90,000 lbs | 3410 lbs | 60 " | 2.84 yd³ | 6 |
AMI’s Fast Track Program features a wide selection of high-volume products that can be manufactured and shipped in a shorter time period with no compromise in quality and at no extra charge.
