HD Pro+ Digging Bucket
Next Generation Productivity that Cycles Faster and Maximizes Payload. AMI PRO+ Series buckets are strong, last just as long and weigh less - gaining extra payload capacity without upsizing your excavator. Built for mass material moving and high-production truck loading, PRO+ buckets offer an even higher capacity to support pass match goals, without sacrificing durability. Step into the next generation of productivity with an advantage that adds up on every pass. Contact your local AMI Attachments dealer or call 1-800-556-9452.
Hardox® In My Body
Lighter-weight Hardox® 500 Tuf steel delivers proven durability, allowing more material to be moved without increasing suspended load.
Material Type
Smooth Outer Shell
By eliminating the need for heavy wear bars, PRO Series buckets are lighter weight and reduce drag for efficient breakout of material.
Full Pull
With a forward edge position, PRO Series buckets penetrate material naturally with less bucket curl required. PRO offers better visibility to the operator and fills faster by pulling through material easier.
Improved Fill Factor
PRO’s profile is capable of holding over 100% fill factor, depending on material.
Lugging Made with Strenx®
Stress and strain across the lugging is handled through high tensile Strenx® performance steel that flexes without cracking.
Speed Load Dual Radius
The dual radius shell in combination with the forward edge position allows the bucket to fill quicker, increasing dig cycle times and reducing partial bucket loads. When curling the bucket the dual radius improves heel clearance saving unnecessary exterior wear.
Low Resistance Tapered Sidewalls
The tapered design improves side wall clearance for less digging resistance and reduced side wear, reducing friction at discharge.
Bucket Selection Guide By Material Application
Specifications - Excavator
| FastTrack | Category | Model | Machine Class | Weight | Width | Capacity | Teeth |
|---|---|---|---|---|---|---|---|
| 300 | HDPXL6080E66 | 65,000 - 90,000 lbs | 4065 lbs | 66 " | 3.59 yd³ | 6 | |
| 300 | HDPXL6080E72 | 65,000 - 90,000 lbs | 4273 lbs | 72 " | 4 yd³ | 7 | |
|
400 | HDPXL80100E61 | 90,000 - 115,000 lbs | 4861 lbs | 61 " | 4 yd³ | 6 |
|
|
400 | HDPXL80100E68 | 90,000 - 115,000 lbs | 5220 lbs | 68 " | 4.5 yd³ | 7 |
|
|
400 | HDPXL80100E74 | 90,000 - 115,000 lbs | 5500 lbs | 74 " | 5 yd³ | 7 |
|
|
400 | HDPXL80100E80 | 90,000 - 115,000 lbs | 5740 lbs | 80 " | 5.5 yd³ | 8 |
|
|
400 | HDPXL80100E86 | 90,000 - 115,000 lbs | 6080 lbs | 86 " | 6 yd³ | 8 |
AMI’s Fast Track Program features a wide selection of high-volume products that can be manufactured and shipped in a shorter time period with no compromise in quality and at no extra charge.
