Tiltrotator Style Ditch Bucket

For ultimate precision and dexterity when using a tiltrotator, this uniquely shaped bucket is ideal for finishing work and backfilling. The extended front edge and reduced side walls give you a sharp edge to shape and smooth material at any angle. The beveled heel also allows the bucket to rotate freely throughout the tiltrotator’s range without impacting the ground. This bucket works with all tiltrotators, including the AMI Attachments AXXIS™ Tiltrotator powered by NOX.

FastTrack Category Model Machine Class Width Capacity Weight
FastTrack Icon 130 DTR2433E48 24,000 - 33,000 lbs 48 " .512 yd³ 630 lbs
FastTrack Icon 130 DTR2433E54 24,000 - 33,000 lbs 54 " 0.542 yd³ 725 lbs
FastTrack Icon 130 DTR2433E64 24,000 - 33,000 lbs 64 " 0.687 yd³ 840 lbs
FastTrack Icon 150 DTR3340E54 33,000 - 45,000 lbs 54 " 0.542 yd³ WOR
FastTrack Icon 150 DTR3340E64 33,000 - 45,000 lbs 64 " 0.821 yd³ 940 lbs
FastTrack Icon 150 DTR3340E72 33,000 - 45,000 lbs 72 " 1.08 yd³ 980 lbs
FastTrack Icon 200 DTR4045E60 45,000 - 55,000 lbs 60 " 1.180 yd³ 1420 lbs
FastTrack Icon 200 DTR4045E64 45,000 - 55,000 lbs 64 " 1.23 yd³ 1500 lbs
FastTrack Icon 200 DTR4045E66 45,000 - 55,000 lbs 66 " 1.32 yd³ 1545 lbs
FastTrack Icon 200 DTR4045E72 45,000 - 55,000 lbs 72 " 1.500 yd³ 1665 lbs
FastTrack Icon 250 DTR4560E72 55,000 - 65,000 lbs 72 " 1.490 yd³ WOR
FastTrack Icon 250 DTR4560E78 55,000 - 65,000 lbs 78 " 1.62 yd³ WOR

FastTrack Logo AMI’s Fast Track Program features a wide selection of high-volume products that can be manufactured and shipped in a shorter time period with no compromise in quality and at no extra charge.

FastTrack Category Model Machine Class Width Capacity Weight
FastTrack Icon 35 DTR0610E36 6,000 - 10,000 lbs. 36 " 4.35 ft³ 205 lbs
FastTrack Icon 35 DTR0610E40 6,000 - 10,000 lbs. 40 " 4.98 ft³ 220 lbs
FastTrack Icon 35 DTR0610E48 6,000 - 10,000 lbs. 48 " 6.24 ft³ 265 lbs
FastTrack Icon 50 DTR1012E36 10,000 - 12,000 lbs 36 " 6.375 ft³ 280 lbs
FastTrack Icon 50 DTR1012E42 10,000 - 12,000 lbs 42 " 7.50 ft³ 320 lbs
FastTrack Icon 50 DTR1012E48 10,000 - 12,000 lbs 48 " 8.625 ft³ 355 lbs
FastTrack Icon 60 DTR1214E42 12,000 - 14,000 lbs 42 " 10.125 ft³ 420 lbs
FastTrack Icon 60 DTR1214E48 12,000 - 14,000 lbs 48 " 12.500 ft³ 475 lbs
FastTrack Icon 75 DTR1416E42 14,000 - 24,000 lbs 42 " 10.125 ft³ 420 lbs
FastTrack Icon 75 DTR1416E48 14,000 - 24,000 lbs 48 " 12.500 ft³ 475 lbs
FastTrack Icon 75 DTR1416E54 14,000 - 24,000 lbs 54 " 14.5 ft³ 546 lbs

FastTrack Logo AMI’s Fast Track Program features a wide selection of high-volume products that can be manufactured and shipped in a shorter time period with no compromise in quality and at no extra charge.

FastTrack Category Model Machine Class Width Capacity Weight
50 LBDTR1214E42 Class 50 42 " 10.125 ft³ 420 lbs
50 LBDTR1214E48 Class 50 48 " 12.500 ft³ 475 lbs

FastTrack Logo AMI’s Fast Track Program features a wide selection of high-volume products that can be manufactured and shipped in a shorter time period with no compromise in quality and at no extra charge.
